| C36 Piston Rings
I desperately need help find rings for my C36 M104 engine. The VIN is
WDB HM36E4TF386984
The stamp on the Piston is
Mahle 91P16+ (89.90mm)
Based on the stamp, I think this is the piston
https://web.tecalliance.net/mahle-catalog/en/parts/287/002%252095%25...
These are the rings that were in the engine (measured by my mechanic).
1.2 x 3.3
1.5 x 3.7
2.5 x 2.2
The dealer's part number through their chain of replacement numbers came up with
A 003 030 92 24
These rings are way too big for this piston and cannot be used.
1.50
1.75
3.00
Needless to say, I need help tracking down the correct rings for this engine. Please Help!
Edited by Braingears 6/30/2022 8:37 AM
|
